T-400E,S,F
EcooGraphix
8442302190
| Availability: | |
|---|---|
| Quantity: | |
Specification
| Model | T800XF | T800XV | |
| Exposing Method | External drum | ||
| Imaging System | 830nm laser | ||
| Max.Output Speed | 35 plates/hour | 42 plates/hour | |
| 1,030×800mm.,Plate sensitivity:100mJ/cm2 | |||
| Plate Size | Max.1,163×940mm.,Min.400×300mm. | ||
| Exposure Size | Max.1,163×924mm.,Min.400×284mm. | ||
| Plate Thickness | 0.15mm-0.3mm | ||
| Resolutions | Standard: dual resolutions 2,400dpi and1.200dpi,or 2,540dpi and 1,270dpi (Option) Variable high resolution option: maximum up to 10,000dpi at fast scan direction | ||
| Repeatability | 0.01mm | ||
| Interface | Optical fiber/GB Ethernet | ||
| Plate Loading | Manual | ||
| Net Weight | 900KG | ||
| Device Size | 2,320×1,080×960mm.(W×L×H) | ||
| Power Supply | Single phase:220V, Power: 4KW(Peak value) | ||
| Environment | Operating temperature range:15-30℃ Recommended temperature:21-25C Humidity:40%-70% | ||
