1. A number of national patents, the performance of GEN 5 machine is ahead of the peers. 2. Modular structure, different functions can be combined according to customer needs, and functions can be upgraded after purchase.
3. Multi-motor transmission has strong power, fast speed, longer service life.
4. Synchronous belt transmission with high speed and low noise.
5. The upper and lower conveyor belts are powered, and there is no curling phenomenon.
6. The new curved arm bracket has a unique shape and a beautiful appearance.
7. The integrated electrical control box is hidden at the bottom of the conveyor, which saves space. Main Technical Data: (Unit: mm)
Model | Box Type | A | B | C min | D min |
ECOO-1100XC | Straight-line box | 170-1100 | 60-700 | 100 | 80 |
Pre-fold box | 200-1000 | 60-700 | 100 | 80 | |
Crash lock bottom box | 200-1000 | 100-700 | 100 | 80 | |
4 corner box | 200-900 | 180-600 | E:30-100 | ||
6 corner box | 200-900 | 180-600 | E:30-100 | ||
| |
Line speed | 0- 300m/min adjustment |
Paperboard | 210~600g/m2 paperboard, Compatible E corrugated board |
Box forming | Single side gluing, Pre-folding, Crash lock bottom, 4/6 corner |
Paper board feeding | Automatic feeding |
Glue type | Cold glue |
Weight | 4600kg |
Dimension | 16000*1300*1300(MM) |
Power | 22KW AC 3PH 380V |
