Model

                 FL-800E                                             FL-800S

Laser Channel

                 16CH

  32CH

Output Speed

                1.25 m² /h

                   2.5 m² /h

Max. Breadth

                                 26"x31"/660mmx800mm

Min. Breadth

100mmx100mm

Plate Type

Heat Corrosive   Film, Thermal PS Plate, Digital Relief Plate, Digital Flexo Plate

Plate Thickness

                                    0.15mm - 1.7mm

Application

Label and trademark

Resolutions

4000dpi; Optional 2400dpi and 3000dpi.

Plate Loading

Manually load and unload

Interface

USB 2.0

Focus Adjust

Dynamic autofocus

Device Size

                                  1,630×1,170×965   mm (WxDxH)

Net Weight

Approximately 800KG

Power

                            Single phase: 220V/50HZ, 60HZ

CTP Machine:   1.5KW, Vacuum: 1.5KW

Environment

                Recommended temperature: 18-30℃, Humidity: 10%- 80%
